NJ2214EM TM01

Size and weight

Ød 70 mm
ØD 125 mm
B 31 mm
rₛ 1.5 mm
r₁ₛ 1.5 mm
s 1.6 mm
Mass 1.5 kg

Data on related components

dₐ min. 77 mm
dₐ max. 82 mm
db min. 86 mm
Dₐ max. 116 mm
rₐ max. 1.5 mm
rb max. 1.5 mm

Data for calculation

Basic dynamic load rating Cᵣ 156 kN
Basic static load rating C₀ᵣ 194 kN
Fatigue load limit Cᵤ 23.7 kN
Reference speed - grease nG 4500 min⁻¹
Reference speed - oil nₒ 5600 min⁻¹
** indicates bearing in NEW FORCE standard
