NUP232M
Size and weight
| Ød | 160 mm |
| ØD | 290 mm |
| B | 48 mm |
| rₛ | 3 mm |
| r₁ₛ | 3 mm |
| s | - mm |
| Mass | 14.7 kg |
Data on related components
| dₐ | min. 174 mm |
| dₐ | max. 180 mm |
| db | min. 197 mm |
| dc | min. - mm |
| dd | max. - mm |
| Dₐ | max. 276 mm |
| Db | min. - mm |
| rₐ | max. 2.5 mm |
| rb | max. 2.5 mm |
Data for calculation
| Basic dynamic load rating | Cᵣ | 511 kN |
| Basic static load rating | C₀ᵣ | 631 kN |
| Fatigue load limit | Cᵤ | 60.3 kN |
| Reference speed - grease | nG | 2000 min⁻¹ |
| Reference speed - oil | nₒ | 2400 min⁻¹ |
** indicates bearing in NEW FORCE standard
