NUP2207ETNG

Size and weight

Ød 35 mm
ØD 72 mm
B 23 mm
rₛ 1.1 mm
r₁ₛ 0.6 mm
s - mm
Mass 0.39 kg

Data on related components

dₐ min. 42 mm
dₐ max. 42 mm
db min. 46 mm
dc min. 50 mm
dd max. - mm
Dₐ max. 65 mm
Db min. - mm
rₐ max. 1 mm
rb max. 0.6 mm

Data for calculation

Basic dynamic load rating Cᵣ 64.3 kN
Basic static load rating C₀ᵣ 64.3 kN
Fatigue load limit Cᵤ 7.84 kN
Reference speed - grease nG 8900 min⁻¹
Reference speed - oil nₒ 10600 min⁻¹
** indicates bearing in NEW FORCE standard
