NU2207ETNG
Size and weight
| Ød | 35 mm |
| ØD | 72 mm |
| B | 23 mm |
| rₛ | 1.1 mm |
| r₁ₛ | 0.6 mm |
| s | 1.6 mm |
| Mass | 0.39 kg |
Data on related components
| dₐ | min. 42 mm |
| dₐ | max. 42 mm |
| db | min. 46 mm |
| dc | min. 50 mm |
| dd | max. - mm |
| Dₐ | max. 65 mm |
| Db | min. - mm |
| rₐ | max. 1 mm |
| rb | max. 0.6 mm |
Data for calculation
| Basic dynamic load rating | Cᵣ | 64.3 kN |
| Basic static load rating | C₀ᵣ | 64.3 kN |
| Fatigue load limit | Cᵤ | 7.84 kN |
| Reference speed - grease | nG | 8900 min⁻¹ |
| Reference speed - oil | nₒ | 10600 min⁻¹ |
** indicates bearing in NEW FORCE standard
