NNU4192M**
Size and weight
| Ød | 460 mm |
| ØD | 760 mm |
| B | 300 mm |
| rₛ | 7.5 mm |
| r₁ₛ | 7.5 mm |
| a | 12 mm |
| b | 22.3 mm |
| s | 12.8 mm |
| Mass | 535 kg |
Data on related components
| dₐ | min. 493 mm |
| dₐ | max. 526 mm |
| Dₐ | min. - mm |
| Dₐ | max. 727 mm |
| rₐ | max. 6 mm |
| rb | max. 6 mm |
Data for calculation
| Basic dynamic load rating | Cᵣ | 6200 kN |
| Basic static load rating | C₀ᵣ | 12300 kN |
| Fatigue load limit | Cᵤ | 575 kN |
| Reference speed - grease | nG | 570 min⁻¹ |
| Reference speed - oil | nₒ | 670 min⁻¹ |
** indicates bearing in NEW FORCE standard
