NN3044
Size and weight
| Ød | 220 mm |
| ØD | 340 mm |
| B | 90 mm |
| rₛ | 3 mm |
| r₁ₛ | 3 mm |
| a | 7.5 mm |
| b | 13.9 mm |
| s | 5.4 mm |
| Mass | 29.6 kg |
Data on related components
| dₐ | min. 233 mm |
| dₐ | max. - mm |
| Dₐ | min. 313 mm |
| Dₐ | max. 327 mm |
| rₐ | max. 2.5 mm |
| rb | max. 2.5 mm |
Data for calculation
| Basic dynamic load rating | Cᵣ | 815 kN |
| Basic static load rating | C₀ᵣ | 1480 kN |
| Fatigue load limit | Cᵤ | 87 kN |
| Reference speed - grease | nG | 1700 min⁻¹ |
| Reference speed - oil | nₒ | 2000 min⁻¹ |
** indicates bearing in NEW FORCE standard
