NN3011K
Size and weight
| Ød | 55 mm |
| ØD | 90 mm |
| B | 26 mm |
| rₛ | 1.1 mm |
| r₁ₛ | 1.1 mm |
| a | 3.2 mm |
| b | 4.8 mm |
| s | 1.2 mm |
| Mass | 0.62 kg |
Data on related components
| dₐ | min. 62 mm |
| dₐ | max. - mm |
| Dₐ | min. 82 mm |
| Dₐ | max. 84 mm |
| rₐ | max. 1 mm |
| rb | max. 1 mm |
Data for calculation
| Basic dynamic load rating | Cᵣ | 64.3 kN |
| Basic static load rating | C₀ᵣ | 81 kN |
| Fatigue load limit | Cᵤ | 9.88 kN |
| Reference speed - grease | nG | 9400 min⁻¹ |
| Reference speed - oil | nₒ | 11000 min⁻¹ |
** indicates bearing in NEW FORCE standard
