AH3232G
For design engineers
Size and weight
| d₀ | 150 mm |
| Ød | 160 mm |
| dz | M170x3 mm |
| h | 20 mm |
| l | 124 mm |
| l₁ | 130 mm |
| z | 12 mm |
| Mass | 3.7 kg |
Data on related components
| Appropriate nut | KM34 |
** indicates bearing in NEW FORCE standard
