81232M
Size and weight
| Ød | 160 mm |
| ØD | 225 mm |
| B | 15 mm |
| H | 51 mm |
| Dᵥᵥ | 21 mm |
| rₛ | 1.5 mm |
| Ød₁ | 222 mm |
| ØD₁ | 163 mm |
| Mass | 6.27 kg |
Data on related components
| dₐ | min. 220 mm |
| Dₐ | max. 168 mm |
| rₐ | max. 1.5 mm |
| Subassembly cage with elements | K 81232M |
| Shaft washer | WS 81232 |
| Housing washer | GS 81232 |
Data for calculation
| Basic dynamic load rating | Cₐ | 477 kN |
| Basic static load rating | C₀ₐ | 1900 kN |
| Fatigue load limit | Cᵤ | 190 kN |
| Reference speed - grease | nG | 450 min⁻¹ |
| Reference speed - oil | nₒ | 600 min⁻¹ |
| Minimum load factor | M | 0.33 |
** indicates bearing in NEW FORCE standard
