3309A-2RSTNG**
Size and weight
| Ød | 45 mm |
| ØD | 100 mm |
| B | 39.7 mm |
| rₛ | 1.5 mm |
| a | 51.4 mm |
| Mass | 1.25 kg |
Data on related components
| dₐ | min. 62 mm |
| Dₐ | max. 90 mm |
| rₐ | max. 1.5 mm |
Data for calculation
| Basic dynamic load rating | Cᵣ | 65.5 kN |
| Basic static load rating | C₀ᵣ | 51.6 kN |
| Fatigue load limit | Cᵤ | 2.35 kN |
| Reference speed - grease | nG | 4000 min⁻¹ |
| Reference speed - oil | nₒ | 4500 min⁻¹ |
** indicates bearing in NEW FORCE standard
