23322EMHD2
Size and weight
| Ød | 110 mm |
| ØD | 240 mm |
| B | 92.1 mm |
| rₛ | 3 mm |
| a | 6 mm |
| b | 11.1 mm |
| Mass | 20.5 kg |
Data on related components
| dₐ | min. 124 mm |
| Dₐ | max. 226 mm |
| rₐ | max. 2.5 mm |
| Appropriate adapter sleeve | - |
| Appropriate withdrawal sleeve | - |
| Appropriate withdrawal nut | - |
Data for calculation
| Basic dynamic load rating | Cᵣ | 900 kN |
| Basic static load rating | C₀ᵣ | 1160 kN |
| Fatigue load limit | Cᵤ | 118.8 kN |
| Reference speed - grease | nG | 1400 min⁻¹ |
| Calculation factor | e | 0.38 |
| Calculation factor | Y1 | 1.8 |
| Calculation factor | Y2 | 2.6 |
| Calculation factor | Y₀ | 1.7 |
| Reference speed - oil | nₒ | 1800 min⁻¹ |
** indicates bearing in NEW FORCE standard
