22336EKMHD2**

Size and weight

Ød 180 mm
ØD 380 mm
B 126 mm
rₛ 4 mm
a 12 mm
b 22.3 mm
Mass 66.8 kg

Data on related components

dₐ min. 2 mm
Dₐ max. 362 mm
rₐ max. 3 mm
Appropriate adapter sleeve H2336
Appropriate withdrawal sleeve AH2336
Appropriate withdrawal nut KM40

Data for calculation

Basic dynamic load rating Cᵣ 1950 kN
Basic static load rating C₀ᵣ 2530 kN
Fatigue load limit Cᵤ 224.6 kN
Reference speed - grease nG 900 min⁻¹
Calculation factor e 0.33
Calculation factor Y1 2.1
Calculation factor Y2 3.1
Calculation factor Y₀ 2
Reference speed - oil nₒ 1200 min⁻¹
** indicates bearing in NEW FORCE standard
