22222EKW33J**
Size and weight
| Ød | 110 mm |
| ØD | 200 mm |
| B | 53 mm |
| rₛ | 2.1 mm |
| a | 4.5 mm |
| b | 8.3 mm |
| Mass | 7.06 kg |
Data on related components
| dₐ | min. - mm |
| Dₐ | max. 188 mm |
| rₐ | max. 2 mm |
| Appropriate adapter sleeve | H322 |
| Appropriate withdrawal sleeve | AH3122X |
| Appropriate withdrawal nut | KM24 |
Data for calculation
| Basic dynamic load rating | Cᵣ | 537 kN |
| Basic static load rating | C₀ᵣ | 653 kN |
| Fatigue load limit | Cᵤ | 69.4 kN |
| Reference speed - grease | nG | 2000 min⁻¹ |
| Calculation factor | e | 0.25 |
| Calculation factor | Y1 | 2.7 |
| Calculation factor | Y2 | 4.1 |
| Calculation factor | Y₀ | 2.7 |
| Reference speed - oil | nₒ | 2800 min⁻¹ |
** indicates bearing in NEW FORCE standard
