2220**
Size and weight
Ød | 100 mm |
ØD | 180 mm |
B | 46 mm |
B₁ | - mm |
rₛ | 2.1 mm |
Mass | 4.72 kg |
Data on related components
dₐ | min. 112 mm |
Dₐ | max. 168 mm |
rₐ | max. 2 mm |
Appropriate adapter sleeve | - |
Data for calculation
Basic dynamic load rating | Cᵣ | 96.9 kN |
Basic static load rating | C₀ᵣ | 40.6 kN |
Fatigue load limit | Cᵤ | 1.56 kN |
Reference speed - grease | nG | 3300 min⁻¹ |
Reference speed - oil | nₒ | 4000 min⁻¹ |
Calculation factor | e | 0.27 |
Calculation factor | Y1 | 2.4 |
Calculation factor | Y2 | 3.6 |
Calculation factor | Y₀ | 2.5 |
** indicates bearing in NEW FORCE standard
